SKU: 5288506

TREK Marlin Gen 3 Frameset

Sale price18,000 ฿
Color: Matte Dnister Black
Size: M (29" Wheel)
Marlin 6 Gen 3
Size Rider Height Inseam
2XS

135 - 145 cm

4'5" - 4'9"

64 - 68 cm

25" - 27"

XS

145 - 155 cm

4'9" - 5'1"

69 - 73 cm

27" - 29"

S

155 - 165 cm

5'1" - 5'5"

74 - 78 cm

29" - 31"

M

165 - 176 cm

5'5" - 5'9"

79 - 83 cm

31" - 33"

ML

173 - 180 cm

5'8" - 5'11"

81 - 86 cm

32" - 34"

L

177 - 188 cm

5'10" - 6'2"

84 - 89 cm

33" - 35"

XL

188 - 195 cm

6'2" - 6'5"

89 - 91 cm

35" - 36"


The world's favourite Trek

Zipping through town, dipping your toes into the trail for the first time or slicing through switchbacks, no matter where you roll, the Marlin is a confidence-inspiring hardtail that’s ready for anything. With versatile trail geometry and Smart Wheel Sizing, this hardtail MTB is built to tackle everything. There’s a good reason it’s the world’s favourite Trek.

Marlin Frame Set is a lightweight aluminium frame ready to be built into the perfect easygoing trail bike. It's loaded with all-new geometry that's more capable than ever, ideal for gaining confidence and speed on the singletrack.

FRAMESET

*Frame
Size: XXS , XS
Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
Size: S , M , ML , L , XL , XXL
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew

WHEELS

Skewer rear
173x5 mm QR
Max tyre size
Frame: 29x2.40" (XXS: 26x2.40", XS & S: 27.5x2.40"), Fork: See manufacturer

DRIVETRAIN

Max. chainring size
1x: See FAQ, 2x: 36T, 3x: 42T

COMPONENTS

Head set
Semi-integrated, 1-1/8"
Rotor size
Max brake rotor sizes - Frame: 180 mm (XXS: 160 mm), Fork: see fork manufacturer

WEIGHTS

Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).

Expanded size range

Marlin ใหม่มีให้เลือก 8 ขนาด เพื่อให้เหมาะและพอดีกับทุกคนมากที่สุด และขนาดล้อแบบ smart wheel sizing โดยเฟรม XXS ใช้ล้อ 26” , เฟรม XS , S ใช้ล้อ 27.5” และเฟรม MD ขึ้นไปใช้ล้อ 29”

Trail-ready, Upgrade-ready

เฟรม Marlin มีมิติเฟรมใหม่สำหรับเส้นทางเทรล พร้อมสำหรับการอัพเกรดได้ง่ายยิ่งขึ้นกว่าที่เคย เพื่อให้คุณเพิ่มประสิทธิภาพของจักรยานคันนี้ให้พร้อมลุยในเส้นทางที่โหดมากขึ้น

Roll stronger with Thru Skew

แกนปลดแบบ Thru Skew ใหม่ มีประสิทธิภาพสูงขึ้น แข็งแรงมากขึ้น ล้อหลังระบบ retention ใหม่ ช่วยล็อคล้อได้แน่นหนากว่าแกนปลดเร็วแบบเดิม มีขนาดความกว้างดุมมาตรฐาน 135 มม.

A better way to produce aluminium

Starting in 2024, we began removing high-emission aluminium from our manufacturing and replacing it with low-emission aluminium made with renewable energy. By October 2025, nearly every alloy bike we make – this one included – had made the switch, driving a major drop in our footprint.

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, and materials.

Weights are based off pre-production products at time of publication. Weights may vary in final production.

ขอสงวนสิทธิ์ในการเปลี่ยนแปลงแก้ไข ข้อมูลรายละเอียดของสินค้า อุปกรณ์ สเปคสินค้า โมเดล สี และวัสดุ บนเว็บไซท์นี้ ซึ่งอ้างอิงจากเว็บไซท์และโรงงานผู้ผลิตต้นทาง และรายละเอียดของราคา ซึ่งอาจมีการเปลี่ยนแปลงได้ตลอดเวลาโดยไม่ต้องแจ้งล่วงหน้า และหากเกิดข้อผิดพลาดจากการลงข้อมูลบนเว็บไซท์นี้ ให้อ้างอิงสเปคสินค้าจริงและเว็บไซท์ของผู้ผลิตต้นทาง รวมถึงข้อมูลราคาอัพเดทของบริษัท โปรไบค์ จำกัด เท่านั้น

น้ำหนักของจักรยานและเฟรมอ้างอิงจากขั้นตอนก่อนทำสีเฟรมในขั้นตอนผลิตจริง ซึ่งน้ำหนักจะเปลี่ยนแปลงไปหลังการผลิตเสร็จสิ้น
