SKU: 1040720

TREK Emonda SL Disc Frameset

Sale price89,000 ฿
Color: Radioactive Red /Trek Black
Size: 56
TREK EMONDA SL
Size Rider Height Inseam
47

152 - 158 cm

5'0" - 5'2"

71 - 75 cm

28" - 30"

50

158 - 163 cm

5'2" - 5'4"

74 - 77 cm

29" - 30"

52

163 - 168 cm

5'4" - 5'6"

76 - 79 cm

30" - 31"

54

168 - 174 cm

5'6" - 5'9"

78 - 82 cm

31" - 32"

56

174 - 180 cm

5'9" - 5'11"

81 - 85 cm

32" - 33"

58

180 - 185 cm

5'11" - 6'1"

84 - 87 cm

33" - 34"


Ultra-light and all-in on speed

The Émonda is our original lightweight road bike, delivering incredible ride quality and an aerodynamic advantage. Designed with ultra-lightweight carbon, we scrutinised every inch of this legendary race bike to make it faster than its predecessor on any flat or up any climb.

Émonda SL Disc frame set is a perfect starting point for your custom lightweight build. Its aerodynamic frame is built with 500 Series OCLV Carbon and designed for disc brakes, which makes for a bike that's not only ultra-fast up climbs and on straightaways, but also one that brakes better in all weather conditions.

FRAMESET

Frame
Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimisation, tapered head tube, internal routing, DuoTrap S-compatible, flat-mount disc, 142x12 mm thru axle
Fork
Émonda SL full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12x100 mm thru axle
Frame fit
H1.5 Race

WEIGHT

Weight
1,245 g - 56 cm (frame-only, painted), 384 g (fork-only, painted)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).

DRIVETRAIN

Front derailleur
Mechanical front derailleurs must have a full-housing stop (example: Shimano toggle front derailleurs)
Max. chainring size
1x: 50T, 2x: 53/39

WHEELS

Skewer front
Bontrager Switch thru axle
Skewer rear
Bontrager Switch thru axle, removable lever
Max tyre size
28 mm

COMPONENTS

Seatpost
Not included
Rotor size
Max brake rotor sizes: 160 mm front and rear

Outstanding bikes for everyone

Every rider – regardless of gender, body type, riding style or ability – deserves a great bike. The all-new Émonda is equipped with size-specific components that deliver a great fit to competitive riders of all genders.

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, and materials.

Weights are based off pre-production products at time of publication. Weights may vary in final production.
