TREK

SKU: 5297166

TREK Domane SL 5 Gen 4

Name: TREK Domane SL 5 Gen 4
Brand: TREK
SKU: 5297166
Price: 118000.0 THB
Availability: OutOfStock

118,000.00 ฿

Color:

Matte Deep Smoke

Size:

50

Domane SL5 Gen 4

Size

Rider Height

Inseam

44

150 - 153 cm

4'11" - 5'0"

71 - 73 cm

28" - 29"

47

152 - 158 cm

5'0" - 5'2"

71 - 75 cm

28" - 30"

50

158 - 163 cm

5'2" - 5'4"

74 - 77 cm

29" - 30"

52

163 - 168 cm

5'4" - 5'6"

76 - 79 cm

30" - 31"

54

168 - 174 cm

5'6" - 5'9"

78 - 82 cm

31" - 32"

56

174 - 180 cm

5'9" - 5'11"

81 - 85 cm

32" - 33"

58

180 - 185 cm

5'11" - 6'1"

84 - 87 cm

33" - 34"

60

185 - 190 cm

6'1" - 6'3"

86 - 90 cm

34" - 35"

62

190 - 195 cm

6'3" - 6'5"

89 - 92 cm

35" - 36"

Variant

0.0

Domane SL 5 is ready to comfortably take on rough roads and long miles in comfort. The lightweight 500 Series OCLV Carbon frame has rear IsoSpeed to smooth out bumps in the road and reduce fatigue, and an integrated cockpit for a setup that looks as good as it feels. It features a reliable Shimano 105 drivetrain, and an easy-access internal storage compartment for stowing ride essentials. Plus, lofty 38mm tire clearance lets you take on any road from tarmac to light gravel.

FRAMESET

Frame
: 500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle
Fork
: Domane SL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle

WHEELS

Hub front
: Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle
Skewer front
: Bontrager Switch thru axle, removable lever
Hub rear
: Bontrager alloy, sealed bearing, centerlock disc, Shimano 11-speed freehub, 142x12mm thru axle
Skewer rear
: Bontrager Switch thru axle, removable lever
Rim
: Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21mm width, Presta valve
Tire
: Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32mm
Tire part
: Bontrager TLR sealant, 6oz
Rim strip
: Bontrager TLR
Max tire size
: 38mm without fenders, 35mm with fenders

DRIVETRAIN

Shifter
: Shimano 105 R7120, 12 speed
Front derailleur
: Shimano 105 R7100, braze-on, down swing
Rear derailleur
: Shimano 105 R7100, 36T max cog
Crank
: Size: 44, 47
Shimano 105 R7100, 50/34, 165mm length
Size: 50, 52
Shimano 105 R7100, 50/34, 170mm length
Size: 54, 56
Shimano 105 R7100, 50/34, 172.5mm length
Size: 58, 60, 62
Shimano 105 R7100, 50/34, 175mm length
Bottom bracket
: Praxis, T47 threaded, internal bearing
Cassette
: Shimano 105 7101, 11-34, 12 speed
Chain
: Shimano SLX M7100, 12 speed
Max chainring size
: 1x: 48T, 2x: 52/36

COMPENENTS

Saddle
: Size: 44, 47, 50, 52
Verse Short Comp, steel rails, 155mm width
Size: 54, 56, 58, 60, 62
Verse Short Comp, steel rails, 145mm width
Seatpost
: Size: 44, 47, 50, 52, 54, 56
KVF aero carbon seatpost, 20mm offset, 280mm length
Size: 58, 60, 62
KVF aero carbon seatpost, 20mm offset, 320mm length
Handlebar
: Size: 44, 47
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 36cm width
Size: 50
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 38cm width
Size: 52
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 40cm width
Size: 54, 56
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 42cm width
Size: 58, 60, 62
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 44cm width
Handlebar tape
: Bontrager Supertack Perf tape
Stem
: Size: 44
Trek RCS Pro, -7 degree, 60mm length
Size: 47
Trek RCS Pro, -7 degree, 70mm length
Size: 50
Trek RCS Pro, -7 degree, 80mm length
Size: 52, 54
Trek RCS Pro, -7 degree, 90mm length
Size: 56, 58
Trek RCS Pro, -7 degree, 100mm length
Size: 60, 62
Trek RCS Pro, -7 degree, 110mm length
Brake
: Shimano 105 hydraulic disc, flat mount
Brake rotor
: Shimano RT70, centerlock, 160mm
Rotor size
: Max brake rotor sizes: 160mm front & rear

ACCESSORIES

Bag
: Bontrager BITS Internal Frame Storage Bag

WEIGHT

Weight
: 56 - 9.02 kg / 19.89 lbs (with TLR sealant, no tubes)
Weight limit
: This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).

Why you'll love it

Domane SL Gen 4's aero Kammtail tube shapes and rear IsoSpeed comfort technology come together for a super fast, light, and smooth ride
This bike is super versatile and equally suited to all-day adventures on the open road, club rides, and racing
The Shimano 105 groupset is reliable and won't break the bank
Road-smoothing IsoSpeed and clearance for up to 38mm tires absorbs fatiguing bumps in the road for a smoother, more comfortable ride
A convenient internal storage compartment gives you a versatile spot to stow tools and gear, while top tube mounts let you cleanly bolt on a bag for all day adventures

The smooth advantage

Newly refined IsoSpeed soaks up fatiguing bumps and saves weight so you can ride stronger longer.

Podium-topping speed

Raced to victory on the infamous cobblestones of Paris-Roubaix, the new carbon Domane is faster than ever thanks to new aerodynamic improvements and an ultra-light design.

Lighter than ever

Light and strong 500 Series OCLV Carbon and a new gram-saving design make this the lightest Domane SL disc ever.

Versatile tire clearance

Comes equipped with fast rolling 32mm tires, but offers clearance for up to 38mm tires so you can confidently ride everything from smooth pavement to light gravel.

Internal storage

Internal downtube storage and top tube bag mounts make it easy to carry everything you need for all-day rides.

Refined integration

Domane is more integrated than ever, with hidden cables and a hidden seatpost clamp.

Shimano 105

With shift technology inherited from mechanical Ultegra and Dura-Ace, Shimano 105 gives you top-shelf shifting at a budget friendly price. Whether you're commuting year-round or training for the big race, Shimano 105 is a workhorse drivetrain that won't hold you back as you grow in the sport.

It's right for you if...

You want a comfy and fast ride that's built for the long haul, and prefer the feel of vibration-damping IsoSpeed and lightweight carbon. Rides might take you over smooth pavement, rough roads, and well beyond. You want a bike with wide tire clearance to get you through it all.

The tech you get

A light and refined 500 Series OCLV Carbon frame and fork with road-smoothing rear IsoSpeed, powerful flat-mount disc brakes, a full 2x12 Shimano 105 groupset, and tubeless ready wheels with wider 700x32 tires. An integrated cockpit, internal storage, top tube mounts, and cable routing add to the bike's capability and sleek look.

The final word

Carbon, comfort, capability. Domane SL 5 is the dream bike for long rides. Its light and fast carbon frame, stable endurance geometry, and road-smoothing rear IsoSpeed keep you comfortable through long miles. You also get the added advantage of a higher-end Shimano 105 drivetrain and powerful disc brakes that let you run wide tires.

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, and materials.

Weights are based off pre-production products at time of publication. Weights may vary in final production.

ขอสงวนสิทธิ์ในการเปลี่ยนแปลงแก้ไข ข้อมูลรายละเอียดของสินค้า อุปกรณ์ สเปคสินค้า โมเดล สี และวัสดุ บนเว็บไซท์นี้ ซึ่งอ้างอิงจากเว็บไซท์และโรงงานผู้ผลิตต้นทาง และรายละเอียดของราคา ซึ่งอาจมีการเปลี่ยนแปลงได้ตลอดเวลาโดยไม่ต้องแจ้งล่วงหน้า และหากเกิดข้อผิดพลาดจากการลงข้อมูลบนเว็บไซท์นี้ ให้อ้างอิงสเปคสินค้าจริงและเว็บไซท์ของผู้ผลิตต้นทาง รวมถึงข้อมูลราคาอัพเดทของบริษัท โปรไบค์ จำกัด เท่านั้น

น้ำหนักของจักรยานและเฟรมอ้างอิงจากขั้นตอนก่อนทำสีเฟรมในขั้นตอนผลิตจริง ซึ่งน้ำหนักจะเปลี่ยนแปลงไปหลังการผลิตเสร็จสิ้น
